Hybrid inverter are already widely used in the world, MPPT Solar Hybrid Inverter is a new all-in-one hybrid solar charge inverter, which integrates solar energy storage &means charging energy storage and AC sine wave output.It can be accessed to a variety of household appliances and office loads, power tools, industrial equipment, and electronic audio and video equipment, including refrigerators, lamps, televisions, fans, air conditioning and other AC loads
7.Selectable input voltage range for home appliances and personal computers;
8.Compatible to mains voltage or generator power;
9.Built-in anti-dust fit for harsh enviroment;
10.Smart battery charger design for optimized battery performance;
11.Dual output.
Technology support of hybrid Inverter
Phase
1-phase
Maximum PV Input Power
6200W
6200W
6500W
Rated Output Power
3600W
4200W
6200W
Maximum Solar Charging Current
120A
GRID-TIE OPERATION
PV INPUT (DC)
Nominal DC Voltage/Maximum DC Voltage
360/500VDC
Start-up Voltage/Initial Feeding Voltage
60VDC/90VDC
MPPT Voltage Range
60~450VDC
Maximum Input Current
1/18A
1/22A
GRID OUTPUT(AC)
Nominal Output Voltage
220/230/240VAC
Output Voltage Range
195.5~253VAC
Nominal Output Current
15.7A
18.2A
27.0A
Power Factor
>0.99
EFFICIENCY
Maximum Conversion Efficiency(DC/AC)
98%
TWO LOAD OUTPUT POWER
Full Load
3600W
4200W
6200W
Maxium Main Load
3600W
4200W
6200W
Maxium Second Load(battery mode)
1200W
1400W
2067W
Maxium Load Cut Off Voltage
26VDC
26VDC
52VDC
Maxium Load Return Voltage
27VDC
27VDC
54VDC
OFF-GRID OPERATION
AC INPUT
AC Start-up Voltage/Auto Restart Voltage
120-140VAC/180VAC
Acceptable Input Voltage Range
90-280VAC or 170-280VAC
Frequency Range
49~51±1HZ
Maximum AC Input Current
30A
30A
40A
PV INPUT (DC)
Nominal DC Voltage/Maximum DC Voltage
360/500VDC
MPPT Voltage Range
60~450VDC
Maximum Input Current
1/18A
1/22A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage
220/230/240VAC
Output Waveform
Pure sine wave
Efficiency(DC to AC)
94%
HYBRID OPERATION
PV INPUT (DC)
Nominal DC Voltage/Maximum DC Voltage
360/500VDC
Start-up Voltage/Initial Feeding Voltage
90VDC/120VDC
MPPT Voltage Range
60~450VDC
Maximum Input Current
1/18A
1/22A
GRID OUTPUT (AC)
Nominal Output Voltage
220/230/240VAC
Output Voltage Range
195.5~253VAC
Nominal Output Current
15.7A
18.2A
27.0A
AC INPUT
AC Start-up Voltage /Auto Restart Voltage
120-140VAC/180VAC
Acceptable Input Voltage Range
90-280VAC or 170-280VAC
Maximum AC Input Current
30A
30A
40A
Maximum AC Charging Current
100A
GENERAL
PHYSICAL
Dimension, DxWxH(mm)
420*350*110
Carton Dimension,D XW XH(mm)
500*415*180
Net Weight (kgs)
8
8.5
9
Gross Weight(kgs)
9
9.5
10
INTERACE
Communication Port
RS232/RS485/WIFI/GPRS/LITHIUM BATTERY
ENVIRONMENT
Humidity
5% to 95% Relative Humidity(Non ~ condensing)
Operating Temperature
-10℃~50℃
STANDARD
Compliance Safety
CE
IFIND HYBRID INVERTER products charger combines the functions of an inverter, solar charger, and battery charger, providing uninterrupted power supply support in a portable size.
With dual PV input and dual MPPT voltage tracking, this hybrid inverter offers maximum efficiency and flexibility. It features different working modes, including purple photovoltaic mode, red battery mode, and blue utility mode, allowing you to adapt to various power sources and optimize energy usage.
Main Features Of hybrid Inverter
1.Pure sine wave solar inverter;
2.Output power factor 1.0;
3.Wifi & GPRS available for IOS and android;
4.Inverter can run without battery;
5.Built-in 100A MPPT solar charge controller;
6.High PV input voltage range(90-500VDC);
7.Selectable input voltage range for home appliances and personal computers;
8.Compatible to mains voltage or generator power;
9.Built-in anti-dust fit for harsh enviroment;
10.Smart battery charger design for optimized battery performance;
11.Dual output.
Technology support of hybrid Inverter
Phase
1-phase
Maximum PV Input Power
6200W
6200W
6500W
Rated Output Power
3600W
4200W
6200W
Maximum Solar Charging Current
120A
GRID-TIE OPERATION
PV INPUT (DC)
Nominal DC Voltage/Maximum DC Voltage
360/500VDC
Start-up Voltage/Initial Feeding Voltage
60VDC/90VDC
MPPT Voltage Range
60~450VDC
Maximum Input Current
1/18A
1/22A
GRID OUTPUT(AC)
Nominal Output Voltage
220/230/240VAC
Output Voltage Range
195.5~253VAC
Nominal Output Current
15.7A
18.2A
27.0A
Power Factor
>0.99
EFFICIENCY
Maximum Conversion Efficiency(DC/AC)
98%
TWO LOAD OUTPUT POWER
Full Load
3600W
4200W
6200W
Maxium Main Load
3600W
4200W
6200W
Maxium Second Load(battery mode)
1200W
1400W
2067W
Maxium Load Cut Off Voltage
26VDC
26VDC
52VDC
Maxium Load Return Voltage
27VDC
27VDC
54VDC
OFF-GRID OPERATION
AC INPUT
AC Start-up Voltage/Auto Restart Voltage
120-140VAC/180VAC
Acceptable Input Voltage Range
90-280VAC or 170-280VAC
Frequency Range
49~51±1HZ
Maximum AC Input Current
30A
30A
40A
PV INPUT (DC)
Nominal DC Voltage/Maximum DC Voltage
360/500VDC
MPPT Voltage Range
60~450VDC
Maximum Input Current
1/18A
1/22A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage
220/230/240VAC
Output Waveform
Pure sine wave
Efficiency(DC to AC)
94%
HYBRID OPERATION
PV INPUT (DC)
Nominal DC Voltage/Maximum DC Voltage
360/500VDC
Start-up Voltage/Initial Feeding Voltage
90VDC/120VDC
MPPT Voltage Range
60~450VDC
Maximum Input Current
1/18A
1/22A
GRID OUTPUT (AC)
Nominal Output Voltage
220/230/240VAC
Output Voltage Range
195.5~253VAC
Nominal Output Current
15.7A
18.2A
27.0A
AC INPUT
AC Start-up Voltage /Auto Restart Voltage
120-140VAC/180VAC
Acceptable Input Voltage Range
90-280VAC or 170-280VAC
Maximum AC Input Current
30A
30A
40A
Maximum AC Charging Current
100A
GENERAL
PHYSICAL
Dimension, DxWxH(mm)
420*350*110
Carton Dimension,D XW XH(mm)
500*415*180
Net Weight (kgs)
8
8.5
9
Gross Weight(kgs)
9
9.5
10
INTERACE
Communication Port
RS232/RS485/WIFI/GPRS/LITHIUM BATTERY
ENVIRONMENT
Humidity
5% to 95% Relative Humidity(Non ~ condensing)
Operating Temperature
-10℃~50℃
STANDARD
Compliance Safety
CE
IFIND HYBRID INVERTER products charger combines the functions of an inverter, solar charger, and battery charger, providing uninterrupted power supply support in a portable size.
With dual PV input and dual MPPT voltage tracking, this hybrid inverter offers maximum efficiency and flexibility. It features different working modes, including purple photovoltaic mode, red battery mode, and blue utility mode, allowing you to adapt to various power sources and optimize energy usage.
